Machining Length 9.1"
# Axis 7
Bar Capacity 2.6"
Chuck Size 0"
Distance Between Centers 27"
Turning Diameter 9.1"
Power 30 hp
Max RPM 5,000 RPM
# of Turrets 2
Hole Thru 3 in
Dimensions 154" x 82" x 82"
Weight 17,200
Bar Capacity: 2.625"
Collet Closer 2
Spindle Speed: 5,000 RPM
Spindle Motor: 30 HP
X Axis Travel: 6.5"
X2 Axis Travels: 7.5"
Z Axis Travel: 31.5"
Z2 Axis Travels: 28.3"
Y Axis Travel: 3.9"
A Axis Travel: 30.3"
Rapid Rate Z Axis: 944 IPM
Rapid Rate X Axis: 787 IPM
Max Turning Dia: 9.1"
Max Turning Length: 9.1"
Max Swing: 9.1"
TURRET:
Turret Configuration (Upper + Lower): 12 + 12
O.D Tool Size: 0.8" x 0.8"
Maximum I.D. Tool Size: 1.3"
Turret Indexing Time: 0.15 Seconds
Maximum Rotary Tool Speed: 5,000 RPM
6 Live tool holders
All static tool holders
Chip Conveyor
High pressure coolant
Tool Pre-Setter
Live Tooling
Sub Spindle
Control CNC (FANUC 18I-TB)
This equipment is currently unavailable. Similar equipment available now is shown below.
