| Swing | 25.25" | 641.35 mm |
| Machining Length | 16.5" | 419.1 mm |
| # Axis | 2 | 2 |
| Chuck Size | 6.5" | 165.1 mm |
| Bar Capacity | 1.75" | 44.45 mm |
| Power | 15 hp | 11.2 kW |
| Max RPM | 6,000 RPM | 6,000 RPM |
| Turning Dia | 14" | 355.6 mm |
| Tailstock | No | No |
| Control | CNC (HAAS) | CNC (HAAS) |
| Weight | 7,900 lbs | 7,900 lbs |
Max Cutting Diameter: 12" (with BOT turret)
X Axis Travel: 7.9"
Z Axis Travel: 16"
Rapid Traverse Rate (X & Z): 1200 IPM
Spindle Bore: 2.31"
Spindle Nose: A2-5
Weight: 7,900 lbs.
This equipment is currently unavailable. Similar equipment available now is shown below.
