2007 HAAS VF-3YT
Have one to sell?
ConditionUsed
1 available
Used Vertical Machining Center, used, with 40"x26"x25" travel, 30 HP motor, 7,500 RPM spindle speed, 30 ATC, and equipped with 4th Axis Table, Coolant Thru Spindle, Programmable Coolant, Haas CNC Control, and Chip Auger.
X Axis Travel: 40"
Y Axis Travel: 26"
Z Axis Travel: 25"
Rapid Rate X Axis: 710 IPM
Rapid Rate Y Axis: 710 IPM
Rapid Rate Z Axis: 710 IPM
Max Table Load: 4,000 LBS
Spindle Motor: 30 HP
Spindle Speed: 7,500 RPM
Spindle Taper: 50
Tool Changer: 30 ATC
Spindle Nose to Table: 7.9" - 32.9"
Max Torque: 340 ft-lbf
Drive System: 2-Speed Gearbox
Max Cutting: 500 ipm
Max Thrust X: 3400 lbf
Max Thrust Y: 4100 lbf
Max Thrust Z: 5600 lbf
Max Tool Weight: 30 lbs
Tool-to-Tool (avg): 4.2 s
Chip-to-Chip (avg): 6.3 s
4th Axis Table, Coolant Thru Spindle, Programmable Coolant, Haas CNC Control, Chip Auger.
