| Swing | 31.75" | 806.45 mm |
| Machining Length | 584.2 mm | 23" |
| # Axis | 4 | 4 |
| Chuck Size | 10" | 254 mm |
| Bar Capacity | 3" | 76.2 mm |
| Power | 30 hp | 22.4 kW |
| Max RPM | 4,500 RPM | 4,500 RPM |
| Turning Dia | 18" | 457.2 mm |
| Tailstock | Yes | Yes |
| Live Tooling | Yes | Yes |
| Control | CNC (HAAS) | CNC (HAAS) |
4500-rpm Spindle
6000-rpm Speed Upgrade for Live Tooling
12-Station BMT65 Turret and C Axis
Automatic Tool Presetter
Auxiliary Coolant Filter
Chip Tray Filter Kit
Belt-Type Chip Conveyor, Lathe
Enclosure Exhaust System
55-Gallon Coolant Tank
High-Pressure Coolant, 300 psi (21 bar)
Standard Low-Volt Transformer
CNC Control Cabinet Cooler
Standard Program Memory, 1 GB
Early Power-Failure Detection Module
Ethernet Interface
HaasConnect: Remote monitoring
HaasDrop
User-Definable Macros
Media Display M-Code; M130
Rigid Tapping
Spindle Orientation
Visual Part Programming System
WiFi Connection for the Haas Control
Parts Catcher
WiFi Camera
10" Hydraulic Chuck, A2-6
Programmable Hydraulic Tailstock
High Intensity Lighting
Inch Measurement Units
4500 Running hours.
This equipment is currently unavailable. Similar equipment available now is shown below.
