X-Axis Travel 14.6"
Y-Axis Travel 10.6"
Z-Axis Travel 10"
U/V Axis Travel 2.36" x 2.36"
Degree Taper Cutting 30 Degree at 3.3"
Inside Tank Dimensions 30.5" x 23.6"
Glass Scale Feedback .00000004 Rotary
Max Workpiece Size 30.5" x 23.6" x 10"
Max Submerged Depth 9.84"
Max Workpiece Weight 1,100 Lbs
Wire Diameter .008" - .012"
Max Cutting Speed .012 Coated Wire, 2.4" Thick, D2 33.5 Sq In/Hr
Positioning Accuracy +/- .0001
Dielectric Capacity 145 Gallons
Power Requirement 200-220/3/60
Machine Footprint 76" x 87" x 77"H
Machine Weight 4,000 Lbs
Control Fanuc 31i-WB
AC &
DC Generator Switchable
4MB Part Storage
AC Servo Drive Motors
Auto Wire Threading
Electric Chiller
Electronic Manuals
10-Second Automatic Threading
13KVA Total Power
15" Color LCD Touch Screen
Rotary Glass Scale Feedback
RS232 Ethernet Interface
Submerged Cutting
AIP2 Discharge Control
Built-in Conversational Programming
Ethernet Connectivity
Fanuc Auto Wire Feed
Keyboard / USB / CF Card and Ethernet
X / Y / U / V / Z Servo Closed Loop System
Note No Wire Alignment Gauge, Transformers Not Included
