Internal Tank Size 41.0” x 32.30” x 16.1”
Maximum Workpiece Weight 3,350 lbs.
Table Travels 23.6” x 15.7” x 16.2”
U/V Travel +/- 3.937”
Resolution .000004”
Taper Angle +/- 3.937”
Factory Rated Cutting Speed 31 sq/in/hr
Wire Diameter .004” - .012”
Max. Workpiece AWF Height 16.0”
Wire Spool Maximum Size 35 lbs.
CNC Control Fanuc 310i-WA (5 Processors)
Floor Space Required 112” x 131” x 93”
Machine Weight 6,600 lbs.
Input Power (Total) 200-220V/3 PH – 13KVA
Submerged Cutting
Automatic Wire Threader
X-Y Glass Scale Feedback
15” Color LCD Touchscreen
Ethernet
5 axis programmable
windows OS interface
dual work lamps
(2) USB Ports
PCMCIA Port
Wireless Wire Alignment Block
Chiller Unit
This equipment is currently unavailable. Similar equipment available now is shown below.
