| X | 31.49" | 799.85 mm |
| Y | 20.47" | 519.94 mm |
| Z | 20.08" | 510.03 mm |
| Power | 30 hp | 22.4 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 30 | 30 |
| Taper | CAT 40 | CAT 40 |
| # Axis | 3 | 3 |
| Control | CNC (Fanuc) | CNC (Fanuc) |
| Weight | 14,500 LBS | 14,500 LBS |
X-Axis Travel: 31.49″
Y-Axis Travel: 20.47″
Z-Axis Travel: 20.08″
Power: 30 HP
Spindle Speed: 15,000 RPM
Tool Change: 30 Side Mount ATC
Spindle Taper: CAT-40
Table Size: 37.4″ x 21.65″
Maximum Table Load: 1,323 LBS
Rapid Traverse Rate (x & y): 2362 IPM
Rapid Traverse Rate (z): 1417 IPM
Change Time Chip to Chip: 4.3 Sec
Change Time Tool to Tool: 1.8 Sec
Approximate Weight: 14,500 LBS
Fanuc Oi-MD CNC Control
Portable MPG Chip Conveyor
This equipment is currently unavailable. Similar equipment available now is shown below.
