2018 FRYER TC-120
Have one to sell?
ConditionUsed
1 available
Used 5-axis vertical machining center with Siemens 840D SL CNC Control. Features include 120" x 32" table, 18,000 RPM spindle, and 24-station tool changer. Equipped with Nikken rotary table, chip conveyor, and more.
Table Size: 120″ x 32″
Table Load: 10,000 LBS
X Axis Travel: 120″
Y Axis Travel: 32″
Z Axis Travel: 28″
B Travel: +/- 100°
A Travel: +/- 360°
Spindle Taper: CAT 40 (Big Plus 40)
Spindle Motor: 40 HP
Spindle Speed: 18,000 RPM
Auto Tool Changer: 24 Stations
Machine Weight: 42,000 LBS
Siemens 840D SL CNC Control
Full 5-Axis Contouring
Through Spindle Coolant- 350 PSI
+/- 100 Degree Roller Cam Tilting Head
Big Plus 40 Spindle
40 HP High Torque Spindle
18,000 RPM Spindle
Fixed Table with 15,000 lbs Capacity
Nikken 10″ High Accuracy Rotary Table & Tailstock
Chip Conveyor
Chip Washdown System
All Available Manuals
