Table Size 158" x 94.5"
Maximum Weight on Table 44,092 lbs.
Distance Between Columns 107.9"
X-axis travel 160"
Y-Axis Travel 98"
Z-Axis Travel 40"
Spindle Taper CAT 50
Spindle Speed 4,500 RPM
Spindle Motor 30 HP
Distance Spindle Nose to Table Top 7.87" - 47.87"
Tool Magazine Capacity 120 Station Tool Changer
Maximum Tool Diameter / Length / Weight 4.92" / 13.78" / 44.1 lbs.
Rapid Traverse Rates X / Y, Z 472 IPM / 591 IPM
Cutting Feedrates 394 IPM
Machine Weight 101,412 lbs.
Machine Control Fanuc 31i Series Control
Coolant Through the Spindle
Chip Conveyor
Chip Augers
Chiller Unit
High Speed Machining
Data Server
Ethernet Interface
RS 232 Port Interface
Spindle Thermal Compensation
3 Roller Type Guide Way on Y Axis
Hardened and Ground Box Ways on Z Axis
Tool Selection Random Method
Electrics 220/480V
This equipment is currently unavailable. Similar equipment available now is shown below.
