| X | 60" | 1,524 mm |
| Y | 50" | 1,270 mm |
| Z | 16" | 406.4 mm |
| Control | CNC (Siemens) | CNC (Siemens) |
W-Axis Travel 30.0 in. (762mm)
Theta Axis Travel ±75°
Electrode Diameter Range Without/AEC
0.004 in. – 0.256 in. (0.1mm – 6.5mm)
Electrode Diameter Range With/AEC
0.012 in. – 0.118 in. (0.3mm – 3.0mm)
Worktable Size
60 in. x 50 in. (1524mm x 1270mm)
Work Envelope
36 in. D x 25 in. H (914mm D x 635mm H)
Maximum Part Height
36 in. with 2 in. long guide
Rotary Table - Nikken CNC321
Table Weight Capacity 2000 lbs. (909kg) maximum
Machine Weight 12000 lbs. (5455kg)
Siemens Sinumerik control
This equipment is currently unavailable. Similar equipment available now is shown below.
