X-Axis Travel: 19″ (480 mm)
Z-Axis Travel: 87″ (2210 mm)
Swing Over Bed: 36.2″ (920 mm)
Swing Over Gap: 45″ (1150 mm)
Swing Over Cross Slide: 21.6″ (550 mm)
Gap Distance: 14.6″ (370 mm)
Spindle Bore: 6.02″ (153 mm)
Spindle Nose: A2-11
Spindle Range: 10-900 RPM
Spindle Motor: 35/25 HP (26/18 kW) WYE Delta
Spindle Torque: 1850 ft-lbs (2500 N.m)
Tailstock Quill Travel: 8″ (200 mm)
Tailstock Quill Diameter: 4.92″ (125 mm)
Tailstock Quill Taper: MT6
Tools: 8
Tooling Size: 1.5″ (38 mm)
Bar Capacity: 2″ (50 mm)
X, Z Axis Rapid Traverse Rate: 500 IPM (12.7 m/min)
Max. Cutting Feed Rate: 100 IPM (2540 mm/min)
Approximate Dimensions: 193″ x 110″ x 90″
Approximate Machine Weight: 23,000 lbs.
Milltronics 8200-B CNC Control
24″ 3-Jaw Chuck
6″ Spindle Bore
Manual Steady Rest
Manual Follow Rest
8 Station Auto Turret
Tailstock
This equipment is currently unavailable. Similar equipment available now is shown below.
