| X | 29.92" | 759.97 mm |
| Y | 29.92" | 759.97 mm |
| Z | 29.92" | 759.97 mm |
| Power | 35 hp | 26.1 kW |
| RPM | 15,000 RPM | 15,000 RPM |
| # ATC | 64 | 64 |
| Taper | CAT 40 | CAT 40 |
| # Axis | 4 | 4 |
| Control | CNC (OKUMA) | CNC (OKUMA) |
Table / Pallet Indexing: Full 4th Axis (Continuous)
Horizontal Table/Pallet Size in mm: 500mm
Number of Pallets: 2
X-Travel: 29.92"
Y-Travel: 29.92"
Z-Travel: 29.92"
Rapid Traverse: 2362 IPM
SPINDLE
Spindle Taper Type: CAT#40
Spindle Taper - Other: Big Plus
Spindle Speed: 15,000 RPM
Spindle Motor: 35 HP
TOOL CHANGER
Tool Magazine Capacity: 64
Tool Changer Type: Chain
CONTROL
Control Make/Model: OSP P300MA CNC Control
Control Options: Coordinate Rotation and Scaling;High Speed Machining;USB;Ethernet / LAN;Synchronized Tapping;Inch/Metric Conversion;Manual Pulse Generator / Pendant
Additional Control Options: 15" Color LCD Touchscreen
4GB Ram Memory
120GB SDD
RS232 Port
MT Connect Full Capacity
OSP Suite Software
Windows Operating System
3D Simulation
Angle Chamfering
Auto Power Shut-Off
Extended Common Variables
Helical Cutting
I-MAP
Pitch Error Compensation
Programmable Travel Limits
Rapid Traverse Override
Schedule Program Function
Simple Load Monitor
Auto Work Gauging
Advanced One Touch IGF
Machine Options: Transformer
Additional Machine Specs: Spindle Chiller
Tool Breakage Detection
Renishaw OMP60
MP Systems Splash Gun
Mayfran Consep 2000 Chip Conveyor
3 Light Tower
Coolant Types: Thru-Spindle Coolant
Coolant PSI: 1,000 PSI
This equipment is currently unavailable. Similar equipment available now is shown below.
