Table Size: 16" x 6"
X-Axis Travel: 8"
Y-Axis Travel: 4"
Workpiece Load: 100 lbs
Resolution: .00005"
Projected Image: Inverted
Screen Diameter: 14"
Screen Material: Fine Ground Glass
Reference Line: Cross Hair
Screen Rotation: +360 Degrees, Fine Feed and Clamp
Angle Display: Vernier Reading, Resolution: 2'
Projection Lens: 10x
Magnification Accuracy (Contour Illumination): +0.1% or Less
Magnification Accuracy (Surface Illumination): +0.15% or Less
Light Source: Halogen (24V 150W)
Optical System: Telecentric System
Functions: Heat Absorbing Filter & Cooling Fan
Power supply: 120VAC, 50/60Hz
Dimension: (W x D x H) 24.1” x 48.8” x 45.6” (612 x 1240 x 1158mm)
Weight: 308lbs (140Kg)
