2006 FADAL VMC-6535
Have one to sell?
ConditionUsed
1 available
Used Vertical Machining Center, featuring Siemens CNC control, 30 HP, 10,000 RPM, 3-Axis, and CAT 50 spindle. Equipped with a 32-tool ATC, coolant systems, chip conveyor, and advanced support systems.
Spindle Taper: CAT 50
Tool Capacity (ATC): 32
Rapid Traverse X/Y Axis: 900 IPM
Rapid Traverse Z-Axis: 700 IPM
Cutting Feed Rate: 400 IPM
Siemens CNC Control
Coolant Through Spindle
Wash Down Coolant System
Remote MPG
Chip Conveyor
Rigid Tapping
Hard Ground Ways (X/Y/Z)
4 Way Surfaces on Saddle
Dual Ball Screw Supports (X/Y/Z)
67 Amps @ 400 VAC
Cool Power
Millimeter Ball Screws
30 HP Baldor Vector Drive
25 HP Spindle Motor
Wired 480 Volts / 3-Phase
Overall Size Machine: 180" LR x 128" FB x 117" High x 34,700 Lbs.
Chip Conveyor: 204" LR x 40" FB x 65" High
