2003 MAZAK INTEGREX 200-IIIST

Chuck Size 8"
Swing 26"
Turning Diameter 26"
Turning Diameter Lower Turret 10.6"
Center Distance 40"
X-Axis Travel 22.83"
X-Axis Travel Lower Turret 5.91"
Y Axis Travel 6.3"
Z-Axis Travel 41.14"
Z-Axis Travel Lower Turret 38.98"
B Axis Head Tilt 225°
C Axis Index 0.001°
W Axis Travel 41.34"
Rapid Traverse (X1/X2/Z1/Z2) 1,496 ipm
Spindle Nose A2-6
Spindle Speed (RPM) 5,000
Main Motor 30 HP
Sub Spindle yes
Sub Spindle Speed 5,000 RPM
Sub Spindle Motor (HP) 25/20 HP
Live Tooling yes
Live Tooling Spindle Taper BT 40
Live Tooling Speed 12,000 RPM - Milling Spindle
Live Tooling Motor 25 HP
Y Axis yes
Turret Capacity 40
