2023 HAAS VF-2
Have one to sell?
ConditionUsed
1 available
Vertical Machining Center, used. Specs: X 30", Y 16", Z 20", Power 30 hp, RPM 10,000, 20 ATC, Taper 40, Table 14" x 36", 4 Axis. Equipped with 4th Axis Drive, HRT-210 Rotary, High-Speed Machining, Through Spindle Coolant, and more.
SPINDLE NOSE TO TABLE MAX: 24”
SPINDLE NOSE TO TABLE MIN: 4”
TOOL CHANGER: 20+1 CAROUSEL
RAPID RATE ALL AXES: 1,000 IPM
MAX TORQUE: 90 FT-LBF
MAX THRUST X: 2550 LBF
MAX THRUST Y: 2550 LBF
MAX THRUST Z: 4200 LBF
4TH AXIS DRIVE
HRT-210 ROTARY
10,000 RPM
HIGH SPEED MACHINING
THROUGH SPINDLE COOLANT
PROGRAMMABLE COOLANT NOZZLE
WIRELESS INTUITIVE PROBING SYSTEM
COORDINATE ROTATION & SCALING
VISUAL PART PROGRAMMING
SPINDLE ORIENTATION
MACROS
ENCLOSURE EXHAUST SYSTEM
CHIP AUGER
