2005 CHIRON FZ-15-S LEAN
Have one to sell?
ConditionUsed
1 available
Travels ( X ): 730 mm
Travels ( Y ): 400 mm
Travels ( Z ): 425 mm
Power max.: 58 kW
Spindle speed max.: 15,000 rpm
Chip-to-chip time from 1.7 s
Axis acceleration X-Y-Z max.: 12 / 12 / 12 m/s2
Rapid feed max.: 75 m/min
Basket Type ATC: 20
Number of tools max.: 158
Tool taper: HSK-63A
Tool weight max.: 10.0 kg
Tool diameter max.: 175 mm
Tool length max.: 300 mm
Automatic workpiece change from: 3.5 s
Spindle distance DZ 2 / 250, 320 oder 400 mm
Spindle distance TZ 4 / 200 mm
BASKET TOOL CHANGER
2-AXIS SWIVEL ROTARY TABLE FOR 5-AXIS SIMULTANEOUS AND COMPLETE MACHINING
